What you’ll learn
  • How to upload Playwright results from Amazon CodeBuild to TestDino
  • How to configure sharded test runs with merged reporting
  • How to set up the TESTDINO_TOKEN as a CodeBuild environment variable
Set up an AWS CodeBuild project to upload Playwright test results to TestDino and view aggregated analytics, failure analysis, and flaky test detection on your dashboard. This guide covers a basic buildspec, sharded buildspec for parallel test execution across multiple shard passes, and merged reporting.

​
Prerequisites

Before setting up, ensure you have:
playwright.config.js
// ...existing config

reporter: [
  ['html', { outputDir: './playwright-report' }],  // Optional
  ['json', { outputFile: './playwright-report/report.json' }],  // ✅ Required
]

​
Set Up Your API Key

Store your TestDino API key as a CodeBuild environment variable so it is available to your build without exposing it in buildspec files.
  1. Open your AWS CodeBuild project
  2. Choose Edit
  3. Open the Environment section
  4. Add an environment variable named TESTDINO_TOKEN
  5. Paste your TestDino API key as the value
  6. Save the project
WarningNever commit your API key directly in buildspec files. Always use CodeBuild environment variables. For additional security, store the key in AWS Systems Manager Parameter Store or AWS Secrets Manager and reference it in your environment configuration.

​
Basic Buildspec Config

For a simple setup without sharding, add the upload step after your Playwright tests.
buildspec.yml
version: 0.2

phases:
  install:
    runtime-versions:
      nodejs: 20
    commands:
      - npm ci
      - npx playwright install --with-deps
  build:
    commands:
      - npx playwright test
  post_build:
    commands:
      - npx tdpw upload ./playwright-report --token="$TESTDINO_TOKEN"

artifacts:
  files:
    - playwright-report/**/*
    - test-results/**/*
  discard-paths: no
TipThe post_build phase runs even if the build phase fails, ensuring test results are uploaded regardless of test outcomes. The artifacts block saves reports for review in S3.

​
Upload Options

FlagDescriptionDefault
--environment <value>Target environment tag (staging, production, qa)unknown
--tag <values>Comma-separated run tags for categorization (max 5)None
--upload-imagesUpload image attachmentsfalse
--upload-videosUpload video attachmentsfalse
--upload-htmlUpload HTML reportsfalse
--upload-tracesUpload trace filesfalse
--upload-filesUpload file attachments (.md, .pdf, .txt, .log)false
--upload-full-jsonUpload all attachmentsfalse
--jsonOutput results as JSON to stdout (for CI/CD)false
-v, --verboseEnable verbose loggingfalse

​
Sharded Test Runs

For larger test suites, CodeBuild runs Playwright across multiple shard passes within a single build. Each shard produces a blob report that gets merged before uploading to TestDino.

​
How it works

  1. CodeBuild runs 4 Playwright shard passes sequentially in a single build
  2. Each shard’s blob report is copied to a dedicated directory
  3. All blob reports are flattened and merged into a single report.json
  4. The merged report is uploaded to TestDino
  5. The build fails only if both tests and the merge/upload fail

​
Full sharded config

buildspec.yml
version: 0.2

phases:
  install:
    runtime-versions:
      nodejs: 20
    commands:
      - npm ci
      - npx playwright install --with-deps
  build:
    commands:
      - rm -rf all-blob-reports playwright-report blob-report
      - |
        TEST_EXIT_CODE=0
        MERGE_AND_UPLOAD_EXIT_CODE=0
        for SHARD in 1 2 3 4; do
          mkdir -p "all-blob-reports/shard-$SHARD"
          npx playwright test --shard=$SHARD/4 || TEST_EXIT_CODE=1
          if [ -d blob-report ]; then
            cp -R blob-report/. "all-blob-reports/shard-$SHARD/"
          fi
          rm -rf blob-report
        done
        mkdir -p playwright-report all-blob-reports-flat
        find all-blob-reports -type f -exec cp {} all-blob-reports-flat/ \;
        if find all-blob-reports-flat -type f | grep -q .; then
          npx playwright merge-reports --reporter=json ./all-blob-reports-flat > playwright-report/report.json || MERGE_AND_UPLOAD_EXIT_CODE=1
        else
          echo "No blob report files were found to merge."
          MERGE_AND_UPLOAD_EXIT_CODE=1
        fi
        if [ -f playwright-report/report.json ]; then
          npx tdpw upload ./playwright-report --token="$TESTDINO_TOKEN" || MERGE_AND_UPLOAD_EXIT_CODE=1
        else
          echo "Skipping TestDino upload because the merged report was not created."
          MERGE_AND_UPLOAD_EXIT_CODE=1
        fi
        test $TEST_EXIT_CODE -eq 0 && test $MERGE_AND_UPLOAD_EXIT_CODE -eq 0

artifacts:
  files:
    - playwright-report/**/*
    - test-results/**/*
  discard-paths: no

​
Key details

Config BlockWhat It Does
runtime-versions: nodejs: 20Uses Node.js 20 managed runtime
for SHARD in 1 2 3 4Runs 4 shard passes sequentially within a single build
--shard=$SHARD/4Passes the shard value directly to Playwright
cp -R blob-report/. "all-blob-reports/shard-$SHARD/"Copies each shard’s blob report to a dedicated directory
find ... -exec cpFlattens all blob files into a single directory for merging
merge-reports --reporter=jsonMerges blob reports into a single report.json
TEST_EXIT_CODE / MERGE_AND_UPLOAD_EXIT_CODETracks failures independently so upload runs even if tests fail
artifactsSaves Playwright reports and test results to S3

​
Rerun Failed Tests

Cache test metadata to enable selective reruns:
buildspec.yml
post_build:
  commands:
    - npx tdpw cache --token="$TESTDINO_TOKEN"
    - npx tdpw upload ./playwright-report --token="$TESTDINO_TOKEN"
Rerun only failed tests on the next build:
buildspec.yml
build:
  commands:
    - |
      FAILED=$(npx tdpw last-failed --token="$TESTDINO_TOKEN")
      if [ -n "$FAILED" ]; then
        npx playwright test $FAILED
      else
        echo "No failed tests found."
      fi
For advanced rerun strategies, caching patterns, and CI optimization techniques, see CI Optimization.

​
Troubleshooting

Move the upload command to the post_build phase, which runs regardless of the build phase exit code. For the sharded buildspec, the script tracks exit codes independently so upload always runs.
Verify your playwright.config.js includes both HTML and JSON reporters with HTML listed first. For sharded runs, ensure each shard’s blob-report directory exists before copying. Check that the find command locates files in all-blob-reports-flat/.
Confirm the environment variable is set in your CodeBuild project under Environment → Environment variables. If using Parameter Store or Secrets Manager, verify the IAM role has read access to the secret.
Ensure each shard pass produces a blob-report directory. Check that your Playwright config includes ['blob'] in the reporter list or that the default blob output is not overridden. Verify the cp -R command copies files before rm -rf blob-report clears them.

​
